Automobile Solenoid Valve Precision Winding Machine

The automotive solenoid valve precision winding machine provides a reliable production solution for automotive parts manufacturing with its efficient and stable performance.

Features:

Precision wire arrangement: simulate manual wire arrangement, through the real-time detection device and the wire arrangement and winding system to form a closed-loop fine-tuning production process, it can correct the cumulative difference between wire arrangement and winding in multi-turn and multi-layer winding at any time, realize the whole row dense winding, and get rid of the inefficiency and instability of manual wire arrangement.

Multi-function microcomputer design: easy to set data, the position of the wire arrangement head can be corrected left and right in the middle of winding, and the starting point and width position can be found to facilitate the winding of special coils or high-precision coils. It also has a 1, 000-set step setting capacity, which can easily set forward and reverse, trapezoidal winding, sparse winding, dense winding, automatic slot crossing and other tasks.

Tension control: adopts magnetic damping tensioner design, adjustable tension, stable operation, neat wire arrangement and high efficiency.

High-precision transmission and control: adopts precision servo motor to drive Taiwan TPI screw rod, and the wire arrangement position control is flatter and more accurate. All imported Japanese NSK bearings have high precision, low noise, high reliability and long life. All sensors are imported brand sensors with high precision and fast response speed.

Application Advantages

Improve production efficiency: It can realize automatic winding, greatly improve production efficiency, reduce production costs, and is suitable for large-scale production.

Improve product quality: High-precision winding technology ensures the consistency and stability of the coil, improves the performance and reliability of the automotive solenoid valve, and reduces failures caused by poor coil winding.

Meet diverse needs: Different winding parameters can be set through programming to meet the winding needs of automotive solenoid valve coils of various specifications and requirements.

Parameters
