The main feature of the Internal Winding Six-Station Winding Machine is the six-station structure, which can perform inner winding operations on multiple workpieces at the same time, greatly improving production efficiency. The application range of the winding machine is very wide, especially in the field of electronic component manufacturing.
| Name and model | LTC-186 |
| Number of stations | Six stations (10 axes) |
| Applicable wire diameter range | 0.10mm-0.5mm |
| Maximum speed | 800rpm/min |
| Applicable stack thickness | 8mm-80mm |
| Applicable motor poles | 3.4.6.8.9.10.12..... |
| Total power | 35KW |
| Power supply | 380V/50HZ three-phase four-wire |
| Air source | 0.45MPa-0.7MPa |
| Appearance | L1200mm*W1450mm*H1580mm |
| Weight | 720KG |
